Strong and Robust

 Lifetime Warranty

(Lifetime for Original boat owner or 5 years from date of purchase)

With only three moving parts, it requires little maintenance

 Highly polished for a very attractive accessory to any trailer boat

Available in two different sizes to suit both small boats under 6 metres long and large boats 6 metres and over in length

Specifications

Boat Catch Weight: 16kg

Suit Boats: 6 metres to 8 tonne

NOTE: if your boat is between 5 and 8 tonne (10,000 and 16,000lb) please contact us about suitable/heavy mounting brackets.

Standard universal mount bracket fits around a 65-100mm   wide bow post

==========

The revolutionary launch and retrieval system.
Boatcatch™ was invented and designed by an Australian abalone diver who wanted to get his boat into and out of the water faster, safer and hassle free.

Made of 100% marine grade stainless steel(316). This is an incredibly strong and robust product that comes with a lifetime warranty. With only three moving parts, it requires little maintenance and being highly polished, Boatcatch is a very attractive accessory to any trailer boat.

Boatcatch model diagram

Everything you need.
Boatcatch comes with a universal mounting bracket, U-bolts, washers, nuts, pull cord, bow eye and spacer to suit most boats as well as a very comprehensive and clear instruction manual to help you install it yourself.

Fits almost any boat & trailer.
Whether you've got a small 'alloy' boat, a large fiberglass boat or even a cat, you can cut the supplied mounting arm and position the Boatcatch to suit just about any boat and trailer combination!

Easy launch.
Once fitted it's ready to use. When about to launch, you simply prepare by releasing the winch cable from your boat in the parking lot. After which, reverse the trailer into the water. Boatcatch allows you to move around until you choose to remotely pull the release lever and calmly motor off.

Fast retrieval.
Position the trailer in the water and when ready, drive your boat in. The Boatcatch has a heavy duty pin that locates inside the eye automatically when retrieving and secures the boat upon the trailer. It's incredibly strong so you can easily drive your vehicle to the parking lot before having to secure the winch cable.

A diagram of Boatcatch fitting a boat.A diagram of Boatcatch on the boat ramp.

Fitting the Boatcatch.
Most handymen who own a drill and some basic spanners can fit the Boatcatch. The device is clamped simply and directly to the trailer bow post with 'u' bolts and nuts. The most technical job is cutting the metal universal mounting kit 'tube' to length with a hand saw or similar tool.

Different trailer sizes.
The device comes in two sizes of the same design. The small size may be fitted to all aluminium boats under 6 metres long, and light duty fibreglass boats under 6 metres. The large unit will accommodate a vessel as small as 6 metres and a boat of any length and having a maximum weight of 8 tonne.

Dimensions of the small Boatcatch model
Boatcatch won't break.
The device comes in two sizes of the same design. The small size may be fitted to boats under 6 meters (20ft)long. The large unit will accommodate a boat 6 metres (20ft) or over in length, but having a maximum weight of 8 tonne (16,000lb). Note, if your boat is between 5 and 8 tonne (10,000 and 16,000lb) please contact us at info@boathardware.com.au about suitable/heavy mounting brackets.

Operating Boatcatch.
One or two people can be used to launch and retrieve with a Boatcatch. The two person method chosen by most operators is where you have an operator for the boat and a driver the car and trailer. When well practiced this makes for a speedy ramp work.
