Jarrett Boat Trailer Winch 2 Speed – Webbing

Jarrett 2 Speed Boat Trailer Winch – 700kg (5:1 / 1:1) with 6m Webbing Strap

The Jarrett Boat Trailer Winch is a heavy-duty, reliable solution for loading boats onto trailers with ease. Featuring a 2-speed gear system, it allows for fast slack retrieval and controlled power when under load, making it ideal for boats up to 6 metres.

Built with a strong steel construction and quality components, this winch is designed for durability and consistent performance in marine environments.

Important Note:

This winch is not designed for lifting or securing loads. It is intended for boat retrieval only.

Features:

• 2-Speed Operation:

 – 1:1 Ratio for fast slack retrieval

 – 5:1 Ratio for controlled pulling under load

• Heavy Duty Build: 4mm steel body for strength and durability

• Smooth Operation: Machined gears and steel bushes

• Corrosion Protection: Electroplated zinc cobalt with powder-coated finish

• Detachable Handle: Easily switch between gear ratios

• Includes Webbing Strap: 6m strap with snap hook

• Spare Parts Available: Serviceable and long-lasting design

Package Includes:

• 1 x Jarrett 2-Speed Trailer Winch

• 1 x 6m Webbing Strap

• 1 x Snap Hook

Specifications:

• Gear Ratio: 5:1 / 1:1

• Rated Capacity (Webbing): 700kg (6860N)

• Breaking Strain (Webbing): 2070kg

• Webbing Length: 6m

• Maximum Webbing Capacity: 9m

• Drum Diameter: 50mm

• Flange Diameter: 127mm

• Drum Width: 52mm

• Max Handle Effort at Rated Load: 25kg

• Winch Weight: 4.1kg

• Ratchet Type: Lever Action

Description:

The Jarrett 2 Speed Boat Trailer Winch is designed to make boat loading safer and more efficient. The dual gear system allows quick retrieval of slack line, then switches to a lower gear for controlled pulling power when needed.

Ideal for aluminium and fibreglass boats up to 6 metres, especially where trailer setups vary or lack keel rollers or side supports. A dependable and practical addition to any boat trailer setup.
